13. Specifications and Default Settings
13.1 Specifications
Model B030-DP08-17D B030-DP16-17D
NetDirector 8-Port 1U Rack-Mount Console
DisplayPort KVM Switch with 17 in. LCD,
Dual Rail
NetDirector 16-Port 1U Rack-Mount Console
DisplayPort KVM Switch with 17 in. LCD,
Dual Rail
Port Selection Methods Pushbutton, OSD, Hotkey Pushbutton, OSD, Hotkey
External Console Ports Displayport (Female), 2 x USB-A (Female) Displayport (Female), 2 x USB-A (Female)
Computer Ports 8 16
RJ11 Firmware Upgrade Port 1 1
Housing Metal, Dual-Rail Metal, Dual-Rail
Power LEDs 1 x Green 1 x Green
Online LEDs 8 x Orange 16 x Orange
Selected LEDs 8 x Green 16 x Green
Power Input Connector IEC-320-C14 IEC-320-C14
I/P Rating 100-240V, 50/60 Hz 1A 100-240V, 50/60 Hz 1A
On/Off Power Switch Yes Yes
Firmware Upgrade Switch 1 (Slide) 1 (Slide)
Additional USB Ports 1 (USB 1.1) 1 (USB 1.1)
Reset Button Yes Yes
Port Selection Pushbuttons 8 16
Keyboard/Mouse Emulation USB (PC, Mac, Sun) USB (PC, Mac, Sun)
Max Video Resolution
(Local and 2nd Console)
1920 x 1080 @ 60 Hz, DDC2B, HDCP 1.4 1920 x 1080 @ 60 Hz, DDC2B, HDCP 1.4
Operating Temperature Range 32 to 104°F / 0 to 40°C 32 to 104°F / 0 to 40°C
Storage Temperature Range -4 to 140°F / -20 to 60°C -4 to 140°F / -20 to 60°C
Humidity 0 to 80% RH, Non-condensing 0 to 80% RH, Non-condensing
Dimensions (H x W x D) 1.74 x 18.90 x 26.77 in. /
44 x 480 x 680 mm
1.74 x 18.90 x 26.77 in. /
44 x 480 x 680 mm
Weight 30.67 lb. / 13.91 kg 30.67 lb. / 13.91 kg
13.2 OSD Factory Default Settings
Model B030-DP08-17D B030-DP16-17D
OSD Hotkey [Scroll Lock] [Scroll Lock] [Scroll Lock] [Scroll Lock]
Port ID Display Duration Always Off Always Off
Port ID Display Mode Port Number + Port Name Port Number + Port Name
Scan Duration 5 Seconds 5 Seconds
Screen Blanker 0 (Disabled) 0 (Disabled)
Logout Timeout 0 (Disabled) 0 (Disabled)
Beeper Y (Enabled) Y (Enabled)
