18
8. Basic Operation
8.1 LCD OSD Configurations
8.1.1 LCD Buttons
The LCD OSD configures the LCD. Four buttons are used to perform the configuration, as described in the table below:
Button Function
MENU • When the LCD OSD Menu function has not been entered, pressing this button initiates the Menu function and
the Main Menu.
• When the LCD OSD Menu function has been entered and has reached a setting choice with the navigation
buttons, pressing this button initiates the adjustment screen.
When navigating through the menus, this button moves the page right or up. When making an adjustment,
it increases the value.
When navigating through the menus, this button moves the page left or down. When making an adjustment,
it decreases the value.
EXIT • When the LCD OSD Menu function has not been entered, pressing this button performs an auto adjustment.
An auto adjustment automatically configures all the settings for the LCD to what the OSD considers their
optimum values to be.
• When you have entered the LCD OSD Menu function, pressing this button exits the current menu and returns
you to the previous menu. Use it to leave an adjustment menu when you are satisfied with the adjustments.
• When at the Main Menu, pressing this button exits the LCD OSD.
8.1.2 Adjustment Settings
LED OSD adjustment settings are described in the table below:
Setting Explanation
Brightness Adjusts the background black level of the screen image.
Contrast Adjusts the foreground white level of the screen image.
Phase If pixel jitter or horizontal line noise is visible on the display, the LCD may have the wrong phase setting.
Adjust the phase setting to eliminate these problems.
Clock If vertical banding is visible on the display, the LCD may have the wrong clock setting. Adjust the clock
setting to eliminate vertical banding.
H-Position Positions the display area on the LCD panel horizontally (moves the display area left or right).
V-Position Positions the display area on the LCD panel vertically (moves the display area up or down).
Color Temperature Adjusts the color quality of the display, such as the warmth value and color balance. The Adjust Color
selection contains a submenu to fine tune RGB values.
Language Selects the OSD display menus’ language.
OSD Duration Sets the amount of time the OSD will display on the screen. If there is no input for the amount of time
chosen, the OSD display turns off.
Reset Resets the adjustments on all menus and submenus to factory default settings.
Note: The Language setting does not return to the factory default, but remains at the one it is currently set to.
