Thermostatic bar mixer shower
1
All dimensions listed in this fitting book regarding the product and installation are approximate.
1.
Fixed spray arm
2.
Fixed showerhead
3.
Rigid riser rail pipe
4.
Handset
5.
Handset
holder
6.
Hose
7.
Eden thermostatic mixer valve
8.
Collar & outlet assembly
-
Arm mounting plate
(not shown)
DIMENSIONS
MAIN COMPONENTS
7
1
3
2
4
5
6
8
2
4
Table of Contents
Table of Contents
2
Dimensions and Main Components
3
Fixed Spray Arm
3
Introduction
4
Site Requirements
4
Safety Warnings
4
Plumbing Requirements
5
Water System Requirements
5
Typical Domestic Installations
6
Installation
9
Preparing the Mixer Valve
9
Siting of the Shower
9
Fitting the Riser Pipe/Fixed Head
10
Leak Testing the Mixer
11
Commissioning
12
Fitting the Mixer Controls
12
Adjusting the Maximum Temperature Stop Setting
12
Temperature Adjustment Range
13
Recommended Outlet Temperatures
13
Operating the Shower (Diverter)
14
Spare Parts
15
Tmv2 and Flow Rates
16
Maintenance
17
Fault Finding
18
