Triton EDEN User Manual

Thermostatic bar mixer shower
2
INTRODUCTION
This book contains all the necessary tting and
operating instructions for your mixer shower.
Please read them carefully and read through
the whole of this book before beginning your
installation.
The shower installation must be carried out by
a suitably competent person and in sequence of
this instruction book.
Care taken during the installation will give a long
and trouble free life from your mixer shower.
SITE REQUIREMENTS
The installation must be in accordance with
water supply (water ttings) regulation 1999
and/or local Bylaws.
Maximum static
pressure (Bar)
10
Flow pressure, Hot
&Cold (Bar)
0.5 to 5
Hot supply
temperature (°C)
55 to 65
Cold supply
temperature ( °C)
Equal to or less than 25
This mixer shower is designed for high pressure
systems found in the UK, but can be installed
with low pressure gravity water systems with
reduced ow rates.
For effective operation of the internal seals, the
maximum static pressure must not be exceeded.
NOTE: Valves operating outside these conditions
cannot be guaranteed by the buildcert scheme to
operate as Type 2 valves.
A stored water temperature of 60°C is
considered sufcient to meet all normal
requirements and will minimise the effects of
scale in hard water areas.
Pressure reducing valve
On sites where the running pressure is above 5
bar, the use of a suitably sized pressure reducing
valve tted in the cold mains supply pipe work
can provide nominally equal pressures at the
mixer shower.
Water minimum ow rate
For best performance within the specied running
pressure range a minimum ow of 8 litres per
minute should be available to both inlets.
Water temperature adjustment and
thermal safety
The mixed water temperature can be adjusted
from cold through to a top limit which must
be preset during installation with full anti-scald
protection throughout the range (35°C to 40°C)
providing the hot water temperature at the inlet
remains 10°C above the outlet temperature.
Should there be a loss of ow to either incoming
supply then water from the shower will stop or
be reduced until both supplies are restored.
SAFETY WARNINGS
a. DO NOT choose a position where the shower
could become frozen.
b. DO NOT connect this mixer shower to any
form of tap or tting not recommended by
the manufacturer.
c. DO NOT allow the inlet pressure or ow
rates to operate outside the guidelines laid
out in ‘site requirements’.
d. DO NOT connect the mixer shower to a
gravity hot supply and a mains cold supply or
vice versa.
APPROVALS
This mixer valve has the following approvals
• WRAS
• TMV2 (BS EN 1111)
Designation: HP-S (high pressure shower
only)
On pressures above 0.5 bar.
