Opal
19
Adjusting the showerhead holder
The holder is supplied already attached to the
rail unit. To adjust the height, press the button
underneath the holder to release the locking
mechanism (fig.30). While still pressing the
button, move the holder up or down to suit
user’s requirement and then release.
FITTING THE HOSE AND
SHOWERHEAD
Feed the flexible hose through the soap dish
opening (fig.31) so the dish acts as a retaining
ring (Water Regulations).
Screw the flexible hose to the shower outlet and
showerhead, making sure the supplied washers
are in place at both ends of the flexible hose
(fig.32).
Place the showerhead into the holder and check
that it fits correctly
(fig.33).
Note: The holder is slightly tapered and the
showerhead and hose will only fit from one
direction.
IMPORTANT: It is the conical end of the hose
which grips into the holder. The showerhead
will not fit in the holder without the hose
attached.
Fig.30 Fig.31
Fig.32
Fig.33
