48
General Information
Rear Seat
1. S e a t l o c k
The seat lock is located on the rear
mudguard, below the rear light unit. To
remove the seat, insert the ignition key into
the seat lock and turn it anti-clockwise while
pressing down on the rear of the seat. This
will release the seat from its lock and allow it
to be slid rearwards for complete removal
from the motorcycle.
To refit the seat, engage the seat's two
brackets under the loops on the subframe
and press down at the rear to engage in the
seat lock.
1. Rear seat brackets
2. Subframe loops
1
cgie
The rider’s seat is only correctly retained
and supported once the rear seat is
correctly fitted. Never ride the motorcycle
with the rear seat detached or removed, as
the front seat will not be secure and may
move.
A loose or detached seat could cause loss
of motorcycle control and an accident.
1
2
2
cgif
