49
General Information
Rider's Seat
1. R i d e r ’ s s e a t
To remove the rider’s seat, remove the rear
seat (see page 48).
Grasp the rider’s seat on either side, and slide
it rearwards and upwards for complete
removal from the motorcycle.
To refit the seat, engage the seat's front rail
into the bracket at the rear of the fuel tank
and lower the rear rail in to the rear brackets.
Push down firmly on the rear of the seat. Refit
the rear seat (see page 48).
Rider’s Seat Height Adjustment
1. R i d e r ’ s s e a t
2. Front seat height adjuster
3. Rear seat height adjuster
4. Low seat height position (rear
shown)
5. High seat height position (rear
shown)
The rider’s seat is adjustable for height by
approximately 25 mm.
To adjust the rider’s seat:
Remove the rider’s seat (see page 49).
To prevent detachment of the seat during
riding, after fitting always grasp the seat
and pull firmly upwards. If the seat is not
correctly secured, it will detach from the
lock. A loose or detached seat could cause
loss of motorcycle control and an accident.
1
cgig
The rider’s seat is only correctly retained
and supported once the rear seat is
correctly fitted. Never ride the motorcycle
with the rear seat detached or removed, as
the front seat will not be secure and may
move.
A loose or detached seat could cause loss
of motorcycle control and an accident.
2
4
5
3
cgih
1
