Trojan TR105 - Parts List

7
PARTS LIST
No. Description Qty
1 Base 1
2 Motor Base 1
3 Main Frame 1
4 Left Upright 1
5 Right Upright 1
6 Bolt (M8 x 70) 2
7 Bolt (M10 x 65) 2
8 Bolt (M8 x 50) 2
9 Bolt (M4 x 8) 2
10 Bolt (M3 x 6) 2
11 Bolt (M8 x 45) 1
12 Bolt (M8 x 40) 2
13 Bolt (M8 x 25) 1
14 Bolt (M8 x 15) 2
16 Bolt (M8 x 65) 2
17 Bolt (M8 x 35) 1
18 Bolt (M6 x 35) 8
19 Bolt (M5 x 25) 6
20 Bolt (M5 x 12) 6
21 Bolt (M5 x 10) 6
22 Bolt (M10 x 45) 4
23 Screw (M4 x 12) 19
24 Screw (M4 x 15) 6
25 Screw (M4 x 10) 9
26 Nut (M10) 2
27 Nut (M8) 6
28 Nut (M5) 6
29 Washer (M10) 4
30 Washer (M8) 2
No. Description Qty
31 Spring Washer (M8) 6
32 Bolt (M8 x 10) 2
33 Console Set 1
34 Safety Key 1
35 Motor Base 1
36 Rear End Cap Left 1
37 Rear End Cap Right 1
38 Base Cover Left 1
39 Base Cover Right 1
40 Power Rack 1
41 Foot Rail 2
42 Base Wheel Cap 2
43 Belly Pan 1
44 Motor Belt 1
45 Black Cushion 8
46 Base Foot Pad 4
47 Base Wheel 2
48 Manual Incline Kit 2
49 Handrail End Cap 2
50 Handrail Foam 2
51 Running Deck 1
52 Running Belt 1
53 Foot Rail Fastener 6
54 Power Rack 1
55 Base Cushion 2
56 Motor 1
57 Controller 1
58 Power Switch 1
59 Circuit Breaker 1
