TrolMaster Aqua-X NFS-1 User Manual

PLEASE READ FIRST INTRODUCTION
Congratulations on your purchase of the NFS-1 Controller . This unit
is an efficient way to fully control your irrigation systems. To ensure
safety, please read this manual carefully before installation and follow
the instructions herein. It will provide detailed instructions that will
help to set up the unit, and to understand its full capability. Any use
or application of this product, other than for its original intended
purposes are prohibited. Store this manual in a secure place for future
reference.
Aqua-X Irrigation Controller is a pioneering and innovational hydroponic
irrigation control system. This smartphone App based system can control
up to 30 outputs (24V or 110V) and monitor the pH, EC and water
temperature of nutrient. Water detectors for watering confirmation
allow the system to send alerts to user when the watering schedule failed.
With its incredible flexibility, everyone could easily automate their
irrigation systems.
The system could control pumps by 110V Control Board and solenoid
valves by 24V Control Board. With the massive control outputs, user
could manager delivery schedules for multiple nutrients, multiple rooms
and multiple zones.
A sensor board with EC/pH/Temp sensors is also available to allow user
to monitor and log all the historical data of their nutrients. When
the measured value exceeds your custom setting range, a warning
message will be sent to your smartphone.
Free smartphone App allows user to monitor and control their watering
schedules at their fingertips. Graphic interface makes multiple schedules
easy to adjust and monitor. The innovational watering confirmation
feature saves enormous loss by watering failures.
1. Introduction 03
2. Facts 04
3. Components 05
4. Installation 06
5. Connections 07-09
6. Buttons 10
7. Start Settings 11
8. Main Menu 12-13
9. Setting Page 14
10. 110V Board Settings 15-19
11.24V Board Settings 19
12. Water Detector Setting 20-23
13. Alarm Settings 24-26
14. System Settings 27-32
15. General Information 33
16. Registration 34
17. Troubleshooting 35-36
18. Specifications 37
CONTENTS
02 03

TrolMaster Aqua-X NFS-1 Specifications

Control Boards

OA6-24 Control Board	Max. 5pcs per set
OA6-110 Control Board	Max. 5pcs per set
DSP-1 Program Device Station	Max. 5pcs per set

Sensors

AMP-2 Sensor Board	Max. 1pc per set
PCT-1 or PCT-2 EC/Temp Sensor	Max. 1pc per set
PPH-1 or PPH-2 pH Sensor	Max. 1pc per set
WD-1 Water Detector	Max. 30pcs per set

Alarm Setpoints

pH Alarm Setpoint Range	0~14
EC Alarm Setpoint Range	0~5
Temp Alarm Setpoint Range	32°- 122°F
pH Alarm Default Value	5~7
EC Alarm Default Value	1~2.5
Temp Alarm Default Value	63°- 70°F

Connectivity

Max Distance to Device to be connected	1000 meters
Control Board Outputs	24V Control Board (6 outputs each), 110V Control Board (6 outputs each), Program Device Station (1 output each), up to 30 outputs per set
