TrolMaster Aqua-X NFS-1 User Manual

GENERAL INFORMATION
WARRANTY
Aqua-X Irrigation Controller (NFS-1) only uses high quality components.
Under normal operating conditions, the mechanical and electronic
components are covered by a three-year warranty from the original
date of purchase. For service return the NFS-1 Irrigation Controller in
the original packaging to your shop with the original sales receipt.
Components that are excluded from warranty are components that
have failed due to abnormal usage.
In the case of defects of the Aqua-X Irrigation Controller (NFS-1), the
Controller will either be replaced or repaired using new or reconditioned
products or parts. If the Controller will be replaced this limited warranty
shall apply to the replacement product for the remaining initial warranty
period, i.e. (three) 3 years from the dateof purchase of the original product.
32 33
Board
Sys tem
F
Temp Format
Time Setting
Serial N umber
System Reset
Calibration
Emerge nc y S top
Board
Auto Resume
in 30 min
Board
Sys tem
F
Temp Format
Time Setting
Serial Number
System Reset
Calibration
Resume
f. Emergency Stop
The Emergency Stop function can be selected when there is abnormal
condition found on the Control Boards. Press the DOWN button to
select “Emergency Stop” and then press the ENTER button to confirm
your selection. The LCD screen of Aqua-X will show “Auto Resume
in 30 min” and then show “Resume” automatically in 30 minutes.
If without midway intervention by pressing the ENTER button. On
the same interface, press the ENTER button again, the Emergency
Stop function will be activated again.
NOTES:
1. When the “Emergency Stop” function is selected, all devices on the
all boards(24V & 110V ) will stop working for half an hour and then
resume to work in 30 minutes. Press the ENTER button again and all
devices on the all boards will stop working for another half an hour.
2. In the stop mode, press the ENTER button within 30 minutes and
the stop mode will be cancelled immediately, and return to normal
working state.

TrolMaster Aqua-X NFS-1 Specifications

Control Boards

OA6-24 Control Board	Max. 5pcs per set
OA6-110 Control Board	Max. 5pcs per set
DSP-1 Program Device Station	Max. 5pcs per set

Sensors

AMP-2 Sensor Board	Max. 1pc per set
PCT-1 or PCT-2 EC/Temp Sensor	Max. 1pc per set
PPH-1 or PPH-2 pH Sensor	Max. 1pc per set
WD-1 Water Detector	Max. 30pcs per set

Alarm Setpoints

pH Alarm Setpoint Range	0~14
EC Alarm Setpoint Range	0~5
Temp Alarm Setpoint Range	32°- 122°F
pH Alarm Default Value	5~7
EC Alarm Default Value	1~2.5
Temp Alarm Default Value	63°- 70°F

Connectivity

Max Distance to Device to be connected	1000 meters
Control Board Outputs	24V Control Board (6 outputs each), 110V Control Board (6 outputs each), Program Device Station (1 output each), up to 30 outputs per set
