Continuous Mode
In continuous mode, the gauge takes a measurement and
updates the display every second. This mode is used for
typical quality control measurements.
Extend the telescoping handle (see Figure 1–1) to reduce the
bending required while taking measurements.
1. To take a measurement in continuous mode, select the
mode as described on page 2–18. Place the gauge on the
test site and press
〈ENTER/START〉.
The gauge displays the measurement results, updated every
second, as shown:
2. Press 〈ESC〉 to return to the Ready screen.
For more information on storing measured data, see the
Storing Data section on page 5-10.
NOTE
If the Temperature option (see page 2–11) is installed, the
mat temperature is also shown in the upper right corner of
the display.
Lat : +hh mm ss. ss
Lng: - hh mm ss. ss
Fi x: ##
# Sat s: ## <ESC>
##. #% Gmb( MA)
##. #% Gmm( Voi dl ess)
D: ###. #
##. #% Voi ds <ESC>
