Troxler PaveTracker Plus 2701-B - Page 59

Model 2701-B
4–11
NOTE
If the Temperature option (see page 2–11) is installed, the
mat temperature is also shown in the upper right corner of
the display.
5. Press 〈ENTER/START〉 to continue. Repeat the previous
steps to take a measurement at up to 30 test locations.
When all locations are complete, press the
〈STORE〉 or
〈ESC〉 key to continue.
If the 〈ESC〉 key is pressed, the gauge displays:
6. Press 〈NO〉 to return to the Ready screen without storing
the results or
〈YES〉 to continue as described below.
If the 〈STORE〉 key is pressed at the end of the
measurements (or if the operator presses
〈ESC〉 then
〈YES〉), the gauge displays:
When storing test results, the gauge can also store project
notes, such as location information, with the measurement
data. To include project notes, press
〈YES〉. The gauge
displays:
I nput Locat i on
Pr ess <ENTER>
End of Meas ur ement
Do You Want To
St or e ?
<YES> or <NO>
Do You Want To
Add Not es?
<YES> or <NO>
4. USING THE GAUGE
