NOTE
The gauge stores only the data shown in the last display. It
does not store the results of each individual reading.
Segregation Mode
In segregation mode, the operator can take up to 30
measurements at selected locations. The gauge then displays
the high, low, and average density of the readings. This mode
enables the operator to determine if there is a large degree of
segregation in the area being measured.
1. Extend the telescoping handle (see Figure 1–1) to reduce
the bending required while taking measurements.
2. To take a measurement in segregation mode, select the
mode as described on page 2–18.
3. Press the 〈ENTER/START〉 key. The gauge displays:
4. Place the gauge on the first test site and press
〈ENTER/START〉. The gauge takes a measurement, then
displays the results:
Lat : +hh mm ss. ss
Lng: - hh mm ss. ss
Fi x: ##
# Sat s: ## <ESC>
Readi ng #: 1
Pr ess <START>
<STORE>/ <ESC> t o End
Hi D: ##. #
Low D: ##. #
Den: ##. # <ENTER>
