20
SECURE OPTIONAL POWER
SUPPLY WITH ZIP TIES
IF THE OPTIONAL POWER SUPPLY
IS BEING USED, CONNECT THE
AUXPS POWER CABLE FROM
THE LEFT PEDESTAL TO THE DC
CONNECTOR ON THE POWER
SUPPLY
IF THE OPTIONAL POWER
SUPPLY IS BEING USED TUCK
THE AUXPS DC CONNECTOR
FROM THE LEFT PEDESTAL
OUT OF THE WAY
STEP 3—ROUTE AND CONNECT LOWER CABLES—INSTALL OPTIONAL
AUXILIARY POWER SUPPLY (IF NEEDED*) CONTINUED
