TrustCare Let’s Fly - Art. No. 0480

Let’s Fly Spare part. Art. No. 0480.
Let’s Fly Service Manual. Revision version No: 2 – Aug 2017
Exchange of rubber springs on rear wheel.
8. www.trustcare.se
1. Unscrew the double screw B and the two screws C
holding the fender.
2. Pull out the brake just enough so you can take away
the rubber springs.
Distance
Rubber
Rubber
5. Put fender in place and push the whole brake assembly
into the rear leg including the fender.
6. Screw the double screw B and the two screws C
back in place.
4. Don’t forget to put the distance sleeve into the yoke.
Fender
B
C C
B
C C
Rubber springs
3. Remove the damaged rubber springs and put in the
new ones.
