TSC M23 - Loading Die-Cut Labels

10
4. Close the supply door until the release buttons click into place.
Note: Please set the sensor type as Continuous.
2.3.2 Loading Die-cut Labels
1. Open the supply door by pulling outward on the release buttons on both sides of
the printer.
Peel bar
Paper exit chute
Peel off enablers
Supply holder
Peel rolle
r
