59
Mode 2
Label
format
sent
Label
format
processed
Waiting
for start
print
signal
Label prints
Ready
for next
label
Data
ready
(Pin 14,
GPO_6)
Not ready
Ready
Print
start
(Pin 3,
GPI_1)
Do not
start
Start
Print
End
(Pin 11,
GPO_3)
Do not
end
End
Mode 3
Label
format
sent
Label
format
processed
Waiting
for start
print
signal
Label prints
Ready for
next label
Data
ready
(Pin 14,
GPO_6)
Not
ready
Ready
