TSC PEX-1131 Series - Print Engine Overview; Front View

- 10 -
2.4 Print Engine Overview
2.4.1 Front View
1. Soft keys
2. Power switch
3. LCD display
4. Wi-Fi antenna
5. LED indicator
6. Navigational keys
7. Media view window
8. Print engine cover
9. USB host
2
1
3
P
o
w
e
r
L
E
D
in
di
c
a
t
o
r
4
6
7
Pri
nt
he
ad
5
8
Pri
nt
he
ad
9
Pri
nt
he
ad
