TSC PEX-1131 Series User Manual

- 48 -
Item
Description
Default
Applicator
Port
This option is used to set the GPO_3 signal when PRINT END.
Selections
Description
Off
The applicator port is off.
Mode 1
Label
format
sent
Label
format
processed
Waiting
for start
print
signal
Label prints
Ready
for next
label
Data ready
(Pin 14,
GPO_6)
not ready
ready
Print start
(Pin 3,
GPI_1)
do not start
start
Print End
(Pin 11,
GPO_3)
do not end
end
Mode 2
Label
format
sent
Label
format
processed
Waiting
for start
print
signal
Label prints
Ready
for next
label
Data ready
(Pin 14,
GPO_6)
not ready
ready
Print start
(Pin 3,
GPI_1)
do not start
start
Print End
(Pin 11,
GPO_3)
do not end
end
Mode 3
Label
format
sent
Label
format
processed
Waiting
for start
print
signal
Lab el prints
Ready
for next
label
Data ready
(Pin 14,
GPO_6)
not ready
ready
Print start
(Pin 3,
GPI_1)
do not start
start
Print End
(Pin 11,
GPO_3)
do not end
end
Mode 4
Label
format
sent
Label
format
processed
Waiting
for start
print
signal
Lab el prints
Ready
for next
label
Data ready
(Pin 14,
GPO_6)
not ready
ready
Print start
(Pin 3,
GPI_1)
do not start
start
Print End
(Pin 11,
GPO_3)
do not end
end
Customized
Use GPIO setting commands for customized settings.
For GPIO command, please refer to TSPL/TSPL2
programming manual.
Off
Start Print
SIG
This determines the trigger conditions for the printer to control GPI 1 and
GPI4.
Level
mode
