TSC Prontronix TTP-244CE User Manual

7
3.2 Instructions to Top Cover Operation
1. Open the printer top
cover.
2. Pull the tabs located on
each side towards the front
of the printer, then lift the
top cover to the maximum
open angle.
3. A top cover support at
the rear of the printer
will engage with lower
inner cover to hold the
printer top cover open.
4. Hold the top cover and
press the top cover support
to disengage the top cover
support with lower inner
cover. Gently close the top
cover.

TSC Prontronix TTP-244CE Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB
Maximum Print Length	90 inches
Communication Interface	USB 2.0, RS-232
Label Width	1.18" - 4.33" (30 - 110 mm)
Label Thickness	0.003 - 0.008" (0.08 - 0.2 mm)
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25-85% non-condensing
Dimensions	232 mm x 156 mm x 288 mm
