TSC Prontronix TTP-244CE User Manual

11
3.5 External Label Roll Mount Installation (Option)
1. Attach an external
paper roll mount on the
bottom of the printer.
2. Insert a 3” label spindle into
a paper roll. And install it on
the external paper roll
mount.
3. Open the printer’s top
cover and separate the
media holders. Then
feeds the media from
the rear external label
entrance chute.
4. Disengage the top cover
support and close the top
cover gently.Use software to
make calibration (Please
refer to chpter 4 and 5.)

TSC Prontronix TTP-244CE Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB
Maximum Print Length	90 inches
Communication Interface	USB 2.0, RS-232
Label Width	1.18" - 4.33" (30 - 110 mm)
Label Thickness	0.003 - 0.008" (0.08 - 0.2 mm)
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25-85% non-condensing
Dimensions	232 mm x 156 mm x 288 mm
