TSC Prontronix TTP-244CE User Manual

12
3.6 Loading Fan-fold Media
1. Open the printer top
cover.
2. Insert the fan-fold media
through the external label
entrance chute.
3. Separate and hold
open the media
holders.
4. Press down the media
holder lock switch to hold
the media firmly.
5. Place the paper,
printing side face up.
Move the media guides
to fit the media width by
turning the guide
adjuster knob.
6. Complete the installation of
fan-fold media..

TSC Prontronix TTP-244CE Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB
Maximum Print Length	90 inches
Communication Interface	USB 2.0, RS-232
Label Width	1.18" - 4.33" (30 - 110 mm)
Label Thickness	0.003 - 0.008" (0.08 - 0.2 mm)
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25-85% non-condensing
Dimensions	232 mm x 156 mm x 288 mm
