TSC Prontronix TTP-244CE User Manual

10
3.4 Loading the Media
1. Open the printer top
cover and separate the
media holders.
2. Place the roll between the
holders then put it onto the
core.
3. Press down the media
holder lock switch to
hold the label roll firmly.
4. Place the paper and make
sure the printing side is
facing up. Move the media
guides to fit the label width.
5. Disengage the top
cover support and close
the top cover
gently.Use software or
hardware to make the
calibration. (Please
refer to chapter 4&5)
6. Loading path for roll label.

TSC Prontronix TTP-244CE Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB
Maximum Print Length	90 inches
Communication Interface	USB 2.0, RS-232
Label Width	1.18" - 4.33" (30 - 110 mm)
Label Thickness	0.003 - 0.008" (0.08 - 0.2 mm)
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25-85% non-condensing
Dimensions	232 mm x 156 mm x 288 mm
