5.3 Printer Function
Printer Function could be found in Printer Configuration. “Printer Function” will be shown on the left side of the window.
Functions
Description
Calibrate Sensor
Detect media types and the size of the label
RTC Setup
Synchronize printer with Real Time Clock on PC
Factory Default
Initialize the printer to default settings
Reset Printer
Reboot printer
Print Test Page
Print test page according to the specified label size and sensor type.
Configuration Page
Print printer configurations
Dump Text
Activate the printer to dump mode
Ignore AUTO.BAS
Ignore AUTO.BAS file when printer boot up.
Exit Line Mode
Exit the line mode to page mode
Enter Line Mode
Leave page mode and enter line mode
Reset WiFi
Restore the WiFi settings to defaults.

TSC Prontronix TTP-244CE Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB
Maximum Print Length	90 inches
Communication Interface	USB 2.0, RS-232
Label Width	1.18" - 4.33" (30 - 110 mm)
Label Thickness	0.003 - 0.008" (0.08 - 0.2 mm)
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25-85% non-condensing
Dimensions	232 mm x 156 mm x 288 mm
