TSC Prontronix TTP-244CE User Manual

24
Print Problem
Problem
Possible Cause
Recovery Procedure
Not Printing
Check if interface cable is well connected to the
interface connector.
Re-connect cable to interface.
The serial port cable pin configuration is not pin to pin
connected.
Please replace the cable with pin to pin connected.
The serial port setting is not consistent between host
and printer.
Please reset the serial port setting.
The port specified in the Windows driver is not correct.
Select the correct printer port in the driver.
The Ethernet IP, subnet mask, gateway is not
configured properly.
Configure the IP, subnet mask and gateway.
No print on the label
Label loaded not correctly.
Follow the instructions in loading the media.
Continuous feeding labels
The printer setting may go wrong.
Please do the initialization and gap/black mark
calibration.
Paper Jam
Gap/black mark sensor sensitivity is not set properly
(sensor sensitivity is not enough)
Calibrate the gap/black mark sensor.
Make sure label size is set properly.
Set label size exactly as installed paper in the
labeling software or program.
Labels may be stuck inside the printer mechanism near
the sensor area.
Remove the stuck label.
Poor Print Quality
Top cover is not closed properly.
Close the top cover completely and make sure the
right side and left side levers are latched properly.
Wrong power supply is connected with printer.
Check if 24V DC output is supplied by the power
supply.
Check if supply is loaded correctly.
Reload the supply.
Check if dust or adhesives are accumulated on the
print head.
Clean the print head.

TSC Prontronix TTP-244CE Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB
Maximum Print Length	90 inches
Communication Interface	USB 2.0, RS-232
Label Width	1.18" - 4.33" (30 - 110 mm)
Label Thickness	0.003 - 0.008" (0.08 - 0.2 mm)
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25-85% non-condensing
Dimensions	232 mm x 156 mm x 288 mm
