TSC TA200 Series User Manual

5
1.6 Media Specifications
Media Specifications
203 dpi models
300 dpi models
Label roll capacity
127 mm (5”) OD
Media type
Continuous, die-cut, black mark, fan-fold, notch
Media wound type
Printing face outside wound & Printing face inside wound
Media width (label +
liner)
Max. 118 mm (4.6”)
Min. 25.4 mm (1.0”)
Media thickness (label
+ liner)
Max. 0.254 mm (10 mil)
Min. 0.06 mm (2.36 mil)
Media core diameter
25.4 mm~38 mm (1”~1.5”)
Label length
10~2,794 mm (0.39”~110”)
10~1,016 mm (0.39”~40”)
Note:
If your label length is less than 25.4mm (1”), we
recommend you to use the perforation at the gap for
easier tear away.
Label length (peeler
mode)
Max. 152.4 mm (6”)
Min. 25.4 mm (1”)
Label length (cutter
mode)
Max. 2,794 mm (110”)
Max. 1,016 mm (40”)
Min. 25.4 mm (1”)
Min. 25.4 mm (1”)
Gap height
Min. 2 mm (0.09”)
Black mark height
Min. 2 mm (0.09”)
Black mark width
Min. 8 mm (0.31”)
