12
4.
Close the peel-off modul
e. Use the
DiagTool to set the
peel-off mode
by selecting “PEE
L” option for
Post-Print Action
setting then clic
k
“Set” button to
enable the peel
-off
mode.
5.
Close the print head
mechanism
and printer cover
.
Printer is ready
for peel-off mode
.
6.
Press the FEED button
to test.
Note:
Please calibrate the g
ap/black m
ark sensor w
hen changing media.
Liner
Liner
Label
23
25
Table of Contents
