3.3 Peel-Off Installation Assembly (Option)

1. Open the top cover.

2. Unscrew the 6 screws in the lower inner cover.

3. Upside down the printer.

4. Unscrew the 2 screws at the lower inner cover

5. Remove the screw at memory card cover.

Remove the

screw

Remove the

screw

Screw

Screws
