3.6 Cutter Module Installation (Option)

1. Pull the top cover open levers to open the top cover.

2. Remove the front panel from the lower cover.

3. Remove 6 screws on the lower inner cover.

4. Upside down the printer.

5. Remove two screws at the hinge

6. Remove the screw that fixes the memory card cover.

Screws

Screw
