TSC TE310 Series

5
1.5 Ribbon Specifications
Ribbon Specifications
Ribbon outside diameter
1” core: Max. 67mm
0.5” core: Max. 40mm
Ribbon length
1” inner core: 300 meters
0.5” inner core: 110 meters
Ribbon core inside diameter
0.5 and 1 inch
Ribbon width
40 ~ 110 mm
Ribbon wound type
Outside wound
1.6 Media Specifications
Media Specifications
TE200
(203 dpi model)
TE300
(300 dpi model)
TE210
(203 dpi model)
TE310
(300 dpi model)
Label roll capacity
Max. 5” OD
Media type
Continuous, die-cut, black mark, fan-fold, notch
Media wound type
Outside wound
Media width
20mm ~ Max. 112 mm
Media thickness
0.06 mm (2.36 mil) ~ 0.19 mm (7.48 mil)
Media core diameter
1” (25.4 mm) & 1.5” (38 mm) ID core
Label length
5 mm ~ Max. printing length
Label length (peeler mode)
N/A
1" ~ 6" (25.4 ~ 152.4 mm)
Label length (cutter mode)
N/A
1" ~ Max. printing length
Gap height
Min. 2 mm (0.09”)
Black mark height
Min. 2 mm (0.09”)
Black mark width
Min. 8 mm (0.31”)
