TSC TTP-225 Series User Manual

24
Self-test
Printer will print the printer configuration after gap/black mark sensor calibration. Self-test
printout can be used to check if there is any dot damage on the heater element, printer
configurations and available memory space.
Self-test printout
Print head test pattern
Printer model name & Main board firmware version
Printed mileage
Main board firmware checksum
Serial port setting
Code page
Country code
Print speed
Print darkness
Label size (width, height)
Gap size (vertical gap, offset)
Sensor sensitivity
File management information
Self-test printout (with printer firmware V7.0 and later version)
Model name
F/W version
Firmware checksum
Printer S/N
TSC configuration file
System date
System time
Printed mileage (meter)
Cutting counter

TSC TTP-225 Series Specifications

General

Brand	TSC
Model	TTP-225 Series
Category	Barcode Reader
Language	English
