TSC TTP-2410MU Series Service Manual

26
26
4. Pull the media sensor module and the label/paper and pull the media sensor module out
of the latch of the sensor module to the mechanism.
6. Replacing the gap/black mark sensor is pushing the gap/back mark sensor that is
reassembling the parts in the reverse procedures but using the piece of label/paper is not
necessary.
