2. ELECTRONICS
2.1 Summary of Board Connectors
Main board
Connector
Description
1
Ethernet RJ-45 connector
2
SD card slot
3
USB device connector
4
USB host connector
5
RS-232C connector
6
Microprocessor
7
GPIO connector
8
Centronics port FPC connector
2
3
5
10
6
13
12
20
19
16
17
4
1
11
7
18
21
22
23
15
9
8
14
