TTP-243 Plus/ 243E Plus/
342 Plus Bar Code Printer
CS0: (0000 0000 ~ 003F FFFF)
CS1: (0040 0000 ~ 007F FFFF)
CS2: (0080 0000 ~ 00BF FFFF)
CS3: (00C0 0000 ~ 0FFF FFFF)
ROM1: (0000 0000 ~ 001F FFFF)
ROM2: (0020 0000 ~ 003F FFFF)
Memory card :(0040 0000~007F FFFF)
Download ROM: (0800 0000 ~ 09F FFFF)
DRAM: (0100 0000~011F~FFFF)
Other Map
Address
Bit
Function
00C0 0000
MOTOR DATA
0
PHASE1
1
PHASE2
2
I0
3
I1
4
/CT EN
5
DC PHASE
6
TPH EN
7
BUZZER
00D0 0000
/USB
0
USB_D0
1
USB_D1
2
USB_D2
3
USB_D3
4
USB_D4
5
USB_D5
6
USB_D6
7
USB_D7
00E0 0000
/CENTRONIC
DATA
0
P_D0
1
P_D1
2
P_D2
3
P_D3
4
P_D4
5
P_D5
6
P_D6
7
P_D7
00F0 0000
OTHER ENABLE
0
LED1
1
LED2
2
LED3
3
PE
4
/SLCT
5
/ERROR
6
/RTC RESET
7
RTC CLK
