8. Remove the four screws of the internal label roll mount.
Fig. 3.18 Remove screws of the label roll mount
9. Move the mechanism about 5 mm in the label feed direction.
10. Take out the internal label roll mount and remove the connector.
Fig. 3.19 Take out the internal label roll
mount and remove the connector
