TSC TTP 243 Plus

33
TTP-243 Plus/ 243E Plus/
342 Plus Bar Code Printer
Note: The key of connector must be positioned upward.
Do not touch the elements of the print head.
Do not disassemble the print head.
8. Tidy up the cable so that it does not protrude or interfere with the ribbon.
9. Reassemble the removed parts in the reverse order of removal.
