TTP-268M/ TTP-366M
Bar Code Printer Service Manual
5. Remove 2 screws from the internal rewinder spindle.
6. Separate the internal rewinder spindle and shaft as above picture.
7. Put the bearing into the internal rewinder shaft hole. (Left side)
8. Insert the gear shaft into the internal rewinder shaft hole.
