TSC TTP-343 Plus User Manual

43
Set Gap Sensor as
Media Sensor and
Calibrate the Gap
Sensor
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns red/amber after 5
green/amber blinks. (Any red/amber will do during the 5
blinks).
 The LED color will be changed as following:
Amber Æ red (5 blinks) Æ amber (5 blinks) Æ green
(5 blinks) Æ green/amber (5 blinks) Æ red/amber (5
blinks) Æ solid green
Skip AUTO.BAS
1. Turn off printer power.
2. Press the FEED button and then turn on power.
3. Release the FEED button when LED becomes solid
green.
 The LED color will be changed as following:
Amber Æ red (5 blinks) Æ amber (5 blinks) Æ green
(5 blinks) Æ green/amber (5 blinks) Æ red/amber (5
blinks) Æ solid green
4. Printer will be interrupted to run the AUTO.BAS program.

TSC TTP-343 Plus Specifications

General

Brand	TSC
Model	TTP-343 Plus
Category	Printer
Language	English
