1-1
CHAPTER 1
Introduction and
Unpacking
The AEROTRAK™ Portable Airborne Particle Counter (particle
counter) has a touch-screen interface and operates on the
included lithium-ion battery or AC power.
These devices have either a 1.0 CFM (28.3 L/min) flow rate,
50 L/min (1.77 CFM) flow rate or a 100 L/min (3.53 CFM) flow
rate and count bin sizes from 0.3 to 25 µm depending on the
model ordered (see table below). Up to 10,000 data sets can be
downloaded for analysis and reporting using the T
RAKPRO™ Lite
Data Download Software included with the device. Each model is
also available with an “N” suffix to indicate a “No Printer” option.
Model Size Range Flow Rate
9310-02 0.3, 0.5, 1.0, 3.0, 5.0, 10.0 μm 28.3 L/min (1 CFM )
9510-02 0.5, 0.7, 1.0, 3.0, 5.0, 10.0 μm 28.3 L/min (1 CFM )
9350-02 0.3, 0.5, 1.0, 2.0, 3.0, 5.0 μm 50 L/min (1.77 CFM)
9350-03 0.3, 0.5, 1.0, 3.0, 5.0, 10.0 μm 50 L/min (1.77 CFM)
9550-02 0.5, 0.7, 1.0, 3.0, 5.0, 10.0 μm 50 L/min (1.77 CFM)
9500-01 0.5, 0.7, 1.0, 3.0, 5.0, 10.0 μm 100 L/min (3.53 CFM)
Typical applications for these particle counters include clean room
monitoring, research, exposure assessment, indoor air quality,
filter testing, clearance testing, quality assurance, and
contaminant migration studies. All A
EROTRAK™ particle counters
meet JIS standards.
Unpacking the AEROTRAK
™
Airborne
Particle Counter
Carefully unpack the AEROTRAK™ Airborne Particle Counter from
the shipping container and verify that all the items shown in the
photos below and listed in the following tables are present.
Contact TSI immediately if items are missing or broken (see
Chapter 7, Contacting Customer Service
for more information).
