Getting Started 2-11
Using Communications Ports
USB B
The standard USB B connector is used to connect the instrument
to a computer running TSI T
RAKPRO™ Lite software for data
downloading and analysis. It is used with a standard USB cable
and T
RAKPRO™ Lite Software (both included).
Ethernet Port
The particle counter is compatible with either 10 or 100 MBps
systems. The green LED indicates that the network is connected.
The yellow LED indicates activity on the network cable. The
instrument cannot be operated using power-over-Ethernet (POE).
The Ethernet LAN connector is a standard 10/100 Mbps
8-Position 8-Contact (8P8C, often called RJ45) modular plug
connection.
Ethernet
Port
USB B (to
computer)
