Wiring the Alarm
System specifications:
• Maximum voltage: 15 VDC (DO NOT USE AC POWER)
• Maximum current: 1 Amp
• Correct polarity must be observed (see pin-outs above)
• The alarm switch, located inside the D
USTTRAK™ monitor must be
located on the ground side of the alarm system.
WARNING
The DUSTTRAK™ monitor Alarm Output function should not be
used to detect hazardous conditions or to provide an alarm for
protecting human life, health or safety.
Caution
The alarm switch must not be wired to AC power! Failure to
properly install the user alarm could damage the DUSTTRAK™
instrument and/or void the instrument warranty! Please read and
follow all instructions before wiring or operating the user alarm.
