TSI Instruments DUSTTRAK 8533 User Manual

Operation
37
Data Label
Pressing the data label will toggle between
PM
1
, PM
2.5
, Resp, PM
10
and Total size
segregated mass fractions.
Data Region
Pressing the data region will bring up a
dialog to show TWA or Average lines.
TWA: Will show a secondary line on the
graph showing the time weighted average
of the data. This line will not show if test
time is less then 15 minutes.
Average: Show a secondary line on the
graph of the running average of the data.
In Graphing Mode, pressing Main returns the instrument to the Main Screen
display.
