Appendix A
56
Battery 8533: Up to 2 Removable Li-Ion
External and Internal charging
Life, 1 battery: >6.5 hours (9 hours
typical for a new battery)
Life, 2 battery: >13 hours
8534: 1 Removable Li-Ion
External and Internal charging
Life: 6 hours typical
Analog out 8533
User selectable output 0 to 5 V or 2 to 20 mA
User selectable scaling
Alarm Out 8533:
STEL
Relay or sound buzzer
Relay
No latching MOSFET
User selectable set point
5% deadband
Connector 4-pin, Mini-DIN connectors
8534:
Sound buzzer
Screen 8533: 5.7” color touchscreen
8534: 3.5” color touchscreen
Gravimetric Sampling 8533: Removable 37 mm Cartridge
EMI/RF Immunity: Complies with Emissions Directive Standard:
EN50081-1:1992
Complies with Immunity Directive Standard:
EN50082-1:1992*
*ESD Shock may require instrument reboot
