Chapter 3
Log Mode (1–5)
Log Name, brings up a virtual keypad to name the
Logged Data file.
Start Date, select the date the test will start.
Start Time, select the time the test will start.
The log interval can be set from 1 second to 60
minutes. It is the amount of time between logged
data points.
Interval between re-zeroing the instrument using
the Auto-Zero accessory. Model 8530 desktop
only.
From 1 minute to the limit of the data storage.
Number of tests, 1 to 999.
Time between tests, 1 minute to 30 days.
Time Constant can be set from 1 to 60 seconds.
This will control the update rate of the main
screen. It is the rolling average of data displayed
on the main screen and is not linked to logged
data in either Manual or Program Log modes.
Use Start Date, option to use programmed start
date or by pass programmed start date.
Use Start Time, option to use programmed start
time or bypass programmed start time.
