Chapter 3
Title Bar
The Title Bar shows common instrument information.
Title of the current screen that is being displayed.
Icon shows if the instrument touchscreen is in an
unlocked or locked condition.
Unlocked:
Locked:
To lock the touchscreen controls, touch the “lock”
icon, immediately followed by three (3) quick touches
on the current screen (Main) word along the top tool
bar.
Repeat the process to unlock the screen.
Show the current % life of the battery and show if the
battery is currently being charged:
Charging: (unfilled portion of the icon is filled
yellow as well as animated to indicate that the
charging is in progress)
Not Charging: (unfilled portion of the icon
transparent)
Indicates the instruments current date and time.
If the instrument is in an alarm status, an alarm icon
will appear in the title bar.
