PCM30U, PCM30U-OCH – User's, Operating and Maintenance Manual
E.1.4.7 Output limiting
Command 1
as received
from
transmission
path
Output state
of command 1
without
limiting
100 ms 50 ms
100 ms
50 ms
80 ms
Output state
of command 1
with limiting to
80 ms
50 ms
E.1.4.8 Acknowledgment function
E.1.4.9 PBS to 2x 4PBS
Special interconnection of commands designed for transmission from one PBS to two 4PBS. Function is
performed and selected only et PBS. Odd commands are routed to A group, even commands are routed to B
group. This option requires special firmware and is not recommended for direct tripping, because is it results
in complicated network structure.
1
2
3
4
5
6
7
8
9
10
1
2
3
4
1
2
3
4
A
B
PBS 4PBS
4PBS
Input 1
Output 1
Ack
Power Channel Modules E-9 446S037.914.14N00
