PCM30U, PCM30U-OCH – User's, Operating and Maintenance Manual
E.1.5.5 Dependability
Figure below represents measured dependability as a function of bit error rate for different To according
to recommendation. To=1,2 means, that command is stated as lost, when delayed more then 1,2 of nominal
transmission time.
Dependability
1,00E-05
1,00E-04
1,00E-03
1,00E-02
1,00E-01
1,00E+00
1,00E-051,00E-041,00E-031,00E-02
BER
Pmc
1
1,2
1,5
Power Channel Modules E-12 446S037.914.14N00
