TurboChef i3 Owner's Manual

GENERAL OVEN INFORMATION
3
Multi Phase
i3 DL (USA) model (i3-9500-14-DL)*
208/240 VAC, 60 Hz, 24 amps
Max Input: 8600/9900 watts
Plug: NEMA 15-30P
i3 BD model (i3-9500-16-BD)
220 VAC, 60 Hz, 24 amps
Max Input: 9100 watts
Plug: IEC 309, 4-pin
i3 LD model (i3-9500-15-LD)
220 VAC, 60 Hz, 24 amps
Max Input: 9100 watts
Plug: NEMA 15-30P
i3 EW model (i3-9500-4-EW)
400 VAC, 50 Hz, 14 amps
Max Input: 9500 watts
Plug: IEC 309, 5-pin
i3 AU model (i3-9500-5-AU)
400 VAC, 50 Hz, 14 amps
Max Input: 9500 watts
Plug: Clipsal 5-pin
i3 KW model (i3-9500-12-KW)
400 VAC, 60 Hz, 14 amps
Max Input: 9500 watts
Plug: IEC 309, 5-pin
i3 ED model (i3-9500-3-ED)
230 VAC, 50 Hz, 24 amps
Max Input: 9500 watts
Plug: IEC 309, 4-pin
i3 SD model (i3-9500-13-SD)
230 VAC, 60 Hz, 24 amps
Max Input: 9200 watts
Plug: IEC 309, 4-pin
i3 JD model (i3-9500-9-JD) - 50 Hz
(i3-9500-11-JD) - 60 Hz
200 VAC, 50 or 60 Hz, 23 amps
Max Input: 8000 watts
Plug: PSE-marked, 4-blade
Electrical Specifications - i3 Oven
TurboChef recommends a Type D circuit breaker for all installations outside the US.
* North America models include a voltage sensor that detects 208 or 240 VAC. The voltage sensor does
not compensate for lack-of or over-voltage installations.
Single Phase
i3 US model (i3-9500-1)*
208/240 VAC, 60 Hz, 40 amps
Max Input: 8300/9600 watts
Plug: NEMA 6-50P, 8/3
i3 BK model (i3-9500-6-BK)
220 VAC, 60 Hz, 40 amps
Max Input: 8800 watts
Plug: IEC 309, 3-pin
i3 LA model (i3-9500-7-LA)
220 VAC, 60 Hz, 40 amps
Max Input: 8800 watts
Plug: NEMA 6-50P
i3 UK model (i3-9500-2-UK)
230 VAC, 50 Hz, 40 amps
Max Input: 9200 watts
Plug: IEC 309, 3-pin
i3 JK model (i3-9500-8-JK) - 50 Hz
(i3-9500-10-JK) - 60 Hz
200 VAC, 50 or 60 Hz, 40 amps
Max Input: 8000 watts
Plug: PSE-marked, 3-blade
