TurboChef i3 Owner's Manual

Figure 6: i5 Oven Cart and Stacking Stand Dimensions
6 INSTALLATION
62.7” (1594 mm)
(handle)
35.5” (902 mm)
(handle)
35.5” (706 mm)
28.6” (726 mm)
1.5” (38 mm)
30.0” (762 mm)
31.5” (800 mm)
32.5” (826 mm)
44.6” (1133 mm)
17.3”
(439 mm)
15.8”
(401 mm)
20.5” (521 mm)
26.5” (673 mm)
24.3” (617 mm)
Optional Installation Items
See Figure 6, below and Figure 7, page 7.
TurboChef Oven Carts
- Part Number: NGC-1217-1
Height: 24” (610 mm)
Width: 27.8” (706 mm)
Depth: 26.625” (676 mm)
- Part Number: NGC-1217-2
Height: 17.3” (439 mm)
Width: 27.8” (706 mm)
Depth: 26.625” (676 mm)
- Part Number: NGC-1217-3
Height: 32” (813 mm)
Width: 27.8” (706 mm)
Depth: 26.625” (676 mm)
TurboChef Stacking Stand
- Part Number: i5-9369
Height: 44.6” (1133 mm)
Width: 32.5” (826 mm)
Depth: 26.5” (673 mm)
NOTE: The stacking stand can only be used with
the 17.3” (439 mm) oven cart (P/N: NGC-1217-2).
Oven Restraint Kit
Part Number: TC3-0242
WARNING: The Oven Restraint Kit will not
prevent the oven from falling off a countertop
if the oven is pulled off or allowed to slide off
the edge. Installation instructions are included
with the kit.
ChefComm Pro
Part Number: CON-7006
ChefComm Pro is a computer program that allows
users of any TurboChef oven to easily create,
update, preview, and distribute menu settings. You
can also save the menu settings to a smart card or
USB device. For more information, call TurboChef
Service at 800.90TURBO or +1 214.379.6000.
ChefComm Limited
Part Number: CON-7016
ChefComm Limited is the same as ChefComm
Pro, except it does not allow menu editing. It is
ideal for those who need to receive menu settings,
but should not be allowed to edit them.
i5
i5

TurboChef i3 Specifications

General

Model	i3
Cooking Chamber	Stainless Steel
Cavity Dimensions	14.5 x 16 x 10 inches
Power Requirements	208-240V, 30A
Control Type	Touchscreen
