Technical Specifications
General
Inputs Two, electronically balanced
Input impedance > 10k ohms
Maximum input level +20dBu
Outputs Six (LMS-D26); Four (LMS-D24), electronically balanced
Output Impedance < 100 ohms
Maximum output level +20dBu into 600 ohm load
Sample rate 96kHz
Frequency Response 10Hz - 40kHz ±1dB (filters disabled)
10Hz - 20kHz ±0.25dB (filters disabled)
THD < 0.01% (+10dBu 20Hz to 20kHz, 30kHz bandwidth)
Dynamic Range >111dB (A weighted, 22kHz bandwidth)
>108dB (unweighted, 22kHz bandwidth)
Serial Comms Data 38.4kbaud, format: 8 data, 1 stop, no parity
Processing
Gain +20dB to -80dB and mute, 0.2dB steps
Output channel source Input A, Input B and SUM
HP filter frequency Off, 10Hz to 25.4kHz, 1/36 octave steps
LP filter frequency 10Hz to 25.4kHz and off, 1/36 octave steps
LP / HP filter type 12, 18 & 24dB / octave Bessel and Butterworth, 12, 24 and 48dB / octave
Linkwitz-Riley and 4
th
or 8
th
order Hardman
Delay Input 400ms, output 80ms
Limiter High performance limiter, adjustable threshold in 0.2dB steps, automatic
time constants
EQ frequency 10Hz - 25kHz, 1/36 octave steps
EQ gain +15dB to -15dB, 0.2dB steps
EQ width 5.0 to 0.1 octaves bandwidth, 1/36 octave steps
Connectors
Audio inputs 3 pin female XLR
Audio outputs 3 pin male XLR
Serial comms 9 pin female ‘D’ type
Network comms future option
Mains 3 pin IEC
Mains Power Universal switch-mode PSU, 85 to 250v AC, 50/60Hz
Consumption < 25 watts
Weight 2.7kg net (5.9 lbs)
Size 1.75"(1U) * 19" * 10" (44 * 482 * 254mm) excluding connectors
Due to continuing product improvement the above specifications are subject to change.
